17240 UFS - Tool for Chamfering Primary Insulation

APPLICATION RANGE: ø15-60mm
SUGGESTED APPLICATION: Any type of primary insulation

Technical Characteristics:

• Designed for chamfered cuts of primary insulation of MV cables (2 x 45°)
• Tool fitted with PTFE plates ensuring optimal sliding on the cable without the use of silicone paste
• Replaceable blade - use order code 17242
• Rotation diameter max. 130mm
• Small and self rotating to work in limited space
• Easy handling through 1 adjusting knob
• Suitable for use up to 45kV

17240 Set Contains:

• UFS - tool for chamfered cuts of primary insulation: 17241
• 2.5 mm Allen wrench: 17100
• Soft nylon case: AB17130

Weight & Dimensions: 170 x 100 x 50mm / 390g

This tool is not suitable for pencilling.
NOT SUITABLE FOR WORK UNDER VOLTAGE
